Features
Cummins diesel engines
• U.S. Tier IV Final and EU SIIIa certified Cummins QSB5-G11 engines which meet emissions limits without the use of a diesel particulate filter (DPF)
• Dual speed engine for operation at 50 or 60 Hz
• Advanced electronic engine controls with integrated aftertreatment system provide superior fuel efficiency while reducing emissions
• High-pressure common rail fuel system reduces engine noise and smoke
• Cummins Direct Flow™ air filtration offering improved air management, longer service life, and easier serviceability
• 2-stage fuel filtration with optimum particle and water separation Control features
• The most advanced, reliable and capable generator set control system on the market today
• Controls provide precise frequency and voltage regulation, alarm and status message display in one easy to operate customer interface Stamford alternators
• 12-lead reconnectable alternators fitted with voltage selection switch
• Permanent magnet excitation for improved performance in non-linear load applications
Engine controls
• Oil pressure and coolant temperature gauge
• Fuel level gauge, Diesel Exhaust Fluid (DEF) level gauge and battery voltage gauge
• Digital Hour meter (5-digit read out)
• Engine control module includes remote start capability
Rental package enclosure
• Camlock & busbar distribution panel
• Sound attenuated, white powder coated lockable enclosure
• 24-hour fuel tank (75% prime) with leak detection sensor
• Single wall fuel tank with 110% fluid containment basin
• Transport Canada Tank
• Roof mounted, single point lift
• Cooling system rated for 122 °F (50 °C) at 100% standby ambient
• Complete engine fluid containment reservoir
• 4 position voltage selector switch (60Hz: 277/480 or 139/240 or 120/208 VAC 3 phase or 120/240 VAC 1 phase). Also first position 50Hz: 230/400 VAC 3 phase)
• 2 position voltage selector (60Hz: 277/480 or 347/600 VAC 3 phase).
• Shore power (15A/120V) – for coolant heater, battery charger, engine oil heater and battery warmer
• Conveniently located analog gauges and heated Human Machine Interface (HMI) display
Rental package options
• Optional Auxiliary Fuel and DEF connections
• DOT approved electric brake trailer with heavy duty center mounted jack, ball or pintle hitch
• DOT approved hydraulic brake trailer with heavy duty center mounted jack, ball or pintle hitch
